Aluminum flooring series
Product features:
Aluminum plate base,good antistatic and radiation-protection capabilities.Produced with mold ,good interchanging capacity;thin joint,pleasing construction effect;waterproof,fireproof and antistatic.
Scope of use:
Widely used in spots with high antistatic demands,such as power plant computer rooms,micro-electric workshops and cleaning workshops and electromagnetic shield rooms etc.
01General overlay floor
Aluminum plate base.high wear-resistance HPL overlay without side stripes;pleas-ing construction effect.
Product parameters:
|
型號 |
Specifications
|
集中載荷（撓度=2mm） |
均布載荷（N/㎡） Uniformly distributed load
|
極限集中載荷（N） Limit of concentrated load
|
滾動載荷（N）
Uniformly distributed load
|
系統電阻（Ω） System resistance
|
|||
|
國際標準 |
國家標準 |
ib |
N |
Kg |
|||||
|
FS700 |
CQ |
600*600*30 |
700 |
1960 |
200 |
9720 |
5880 |
980 |
1*105-9
|
|
FS800 |
Q |
600*600*35 |
800 |
2950 |
300 |
12500 |
8850 |
2255 |
|
|
FS1000 |
B |
600*600*40 |
1000 |
4450 |
450 |
23000 |
13350 |
3560 |
|
|
FS1250 |
Z |
600*600*45 |
1250 |
5560 |
560 |
33000 |
16680 |
4450 |
|
